Chinese Physics C > 2016, Vol. 40 > Issue(8): 086004 DOI: 10.1088/1674-1137/40/8/086004

Design and optimization of resistive anode for a two-dimensional imaging GEM detector

1.
State Key Laboratory of Particle Detection and Electronics, Beijing 100049, China
2.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
3.
University of Chinese Academy of Sciences, Beijing 100049, China
4.
Zhengzhou University, Zhengzhou 450001, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A resistive anode for two-dimensional imaging detectors, which consists of a series of high resistivity pads surrounded by low resistivity strips, can provide good spatial resolution while reducing the number of electronics channels required. The optimization of this kind of anode has been studied by both numerical simulations and experimental tests. It is found that to obtain good detector performance, the resistance ratio of the pads to the strips should be larger than 5, the nonuniformity of the pad surface resistivity should be less than 20\%, a smaller pad width leads to a smaller spatial resolution, and when the pad width is 6 mm, the spatial resolution (σ) can reach about 105 μm. Based on the study results, a 2-D GEM detector prototype with optimized resistive anode is constructed and a good imaging performance is achieved.
- resistive anode,
- GEM,
- two dimensional detector,
- spatial resolution,
- imaging distortion

References

[1]	F. Sauli et al,Nucl.Instrum.Methods A 8: 386 (1997)
[2]	D. Abbaneo et al, JINST, 8: C12031 (2013)
[3]	F. Thibaud et al, JINST, 9: C02005 (2014)
[4]	A. Balla al,Nucl.Instrum.Methods A 628: 194-198 (2011)
[5]	M. Lampton et al, Review of Scientific Instruments, 50(9): 1093-1097 (1979)
[6]	T. Doke et al,Nucl.Instrum.Methods A 261: 605-609 (1987)
[7]	A. Banu et al,Nucl.Instrum.Methods A 593: 399 (2008)
[8]	A. Sarvestani et al,Nucl.Instrum.Methods A 419: 444 (1998)
[9]	M. Y. Dong et al, Chin. Phys. C, 37(2): 026002 (2013)
[10]	H. Wagner et al,Nucl.Instrum.Methods A 482: 334-346 (2002)
[11]	Q. L. Xiu et al, Chin. Phys. C, 37: 106002 (2013)
[12]	H. Wagner et al,Nucl.Instrum.Methods A 523: 287 (2004)
[13]	L. H. Wu, Study of the offline calibration for the BESIII drift chamber and the beam test of a prototype, Ph.D. Thesis(Beijing:Institute of High Energy physics, CAS, 2007)(in Chinese)
