Chinese Physics C > 2016, Vol. 40 > Issue(7): 079001 DOI: 10.1088/1674-1137/40/7/079001

Thermal stability and separation characteristics of anti-sticking layers of Pt/Cr films for the hot slumping technique

1.
MOE Key Laboratory of Advanced Micro-Structured Materials, Institute of Precision Optical Engineering, School of Physics Science and Engineering, Tongji University, Shanghai 200092, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The thermal stability and separation characteristics of anti-sticking layers of Pt/Cr films are studied in this paper. Several types of adhesion layers were investigated:10.0 nm Pt, 1.5 nm Cr+50.0 nm Pt, 2.5 nm Cr+50.0 nm Pt and 3.5 nm Cr+50.0 nm Pt fabricated using direct current magnetron sputtering. The variation of layer thickness, roughness, crystallization and surface topography of Pt/Cr films were analyzed by grazing incidence X-ray reflectometry, large angle X-ray diffraction and optical profiler before and after heating. 2.5 nm Cr+50.0 nm Pt film exhibits the best thermal stability and separation characteristics according to the heating and hot slumping experiments. The film was also applied as an anti-sticking layer to optimize the maximum temperature of the hot slumping technique.
- hot slumping technique,
- anti-sticking layers,
- Pt/Cr film,
- thermal stability,
- separation characteristic

References

[1]	J. E. Koglin, C. M. Chen, J. C. Chonko et al, Proc. SPIE, 5488(46):1-12(2004)
[2]	J. E Koglin, F. E. Christensen, W. W. Craig et al, Proc. SPIE, 5900X:1-10(2005)
[3]	D. Spiga, V. Cotroneo, S. Basso et al, Astron. Astrophys., 505(1):373-384(2009)
[4]	P. Conconi, S. Campana, G. Tagliaferri et al, Monthly Notices of the Royal Astronomical Society, 405(2):877-886(2010)
[5]	D. Spiga, Astron. Astrophys., 529:A18(2011)
[6]	F. Frassetto, S. Coraggia, P. Miotti et al, Opt. Express, 21(15):18290-18303(2013)
[7]	H. Awaki, H. Kunieda, M. Ishida et al, Appl. Opt., 53(32):7664-7676(2014)
[8]	L. Raimondi, D. Spiga, Astron. Astrophys., 573:A22(2015)
[9]	K. S. Chon, Y. Namba, K. H. Yoon, Appl. Opt., 45(19):4609-4616(2006)
[10]	H. Wolter, Annalen der Physik, 445(1-2):94-114(1952)
[11]	M. C. Weisskopf, S. L. O'Dell, R. F. Elsner et al, Proc. SPIE, 2515:312-329(1995)
[12]	O. Citterio, P. Conconi, M. Ghigo et al, Proc. SPIE, 1742:256-263(1993)
[13]	P. J. Serlemitsos, Y. Soong, K. W. Chan et al, Publications of the Astronomical Society of Japan, 59(sp1):S9-S21(2007)
[14]	W. W. Zhang, D. A. Content, S. J. Henderson et al, Proc. SPIE, 5488:820-828(2004)
[15]	W. W. Zhang, J. Bolognese, K. W. Chan et al, Proc. SPIE, 668802:1-12(2007)
[16]	M. Ghigo, S. Basso, R. Canestrari et al, Proc. SPIE, 74370P:1-15(2009)
[17]	W. W. Zhang, J. Bolognese, G. Byron et al, Proc. SPIE, 73600J:1-10(2009)
[18]	M. Civitani, S. Basso, A. Bianco et al. Int. Conference on Space Optics, 4:8(2010)
[19]	G. Pareschi, S. Basso, M. Bavdaz et al, Proc. SPIE, 81470L (2011)
[20]	W. W. Zhang, M. P. Biskach, P. N. Blake et al, Proc. SPIE, 81470K:1-12(2011)
[21]	W. W. Zhang, Proc. SPIE,74370N:1-11(2009)
[22]	Proserpio L. Development of the glass slumping technology for the production of the X-ray mirrors aboard the international X-ray observatory optical module, Ph. D. Thesis, (Universit degli Studi dell'Insubria, 2011)
[23]	Y. Dong, Proc. SPIE, 91443O:1-7(2014)
[24]	Z. Wang, Z. Shen, B. Mu et al, Proc. SPIE, 91441E:1-6(2014)
[25]	S. Romaine, R. Bruni, P. Gorenstein et al, Proc. SPIE, 77323T:1-6(2010)
