Chinese Physics C > 2016, Vol. 40 > Issue(7): 076202 DOI: 10.1088/1674-1137/40/7/076202

Spot size measurement of a flash-radiography source using the pinhole imaging method

1.
Key Laboratory of Pulsed Power, Institute of Fluid Physics, China Academy of Engineering Physics, Mianyang 621900, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The spot size of the X-ray source is a key parameter of a flash-radiography facility, and is usually quoted as an evaluation of the resolving power. The pinhole imaging technique is applied to measure the spot size of the Dragon-I linear induction accelerator, by which a two-dimensional spatial distribution of the source spot is obtained. Experimental measurements are performed to measure the spot image when the transportation and focusing of the electron beam are tuned by adjusting the currents of solenoids in the downstream section. The spot size of full-width at half maximum and that defined from the spatial frequency at half peak value of the modulation transfer function are calculated and discussed.
- spot size,
- X-ray source,
- pinhole,
- linear induction accelerator

References

[1]	T. P. Starke, IEEE Transactions on Nuclear Science, 2:1402-1404(1983)
[2]	T. J. Boyd, Jr. B. T. Rogers, R. R. Tesche, and Douglas Venable, Rev. Sci. Instrum. 36:1401-1408(1965)
[3]	P. D. A. Champney, P. W. Spence, Pulsed Electron Accelerators for Radiography and Irradiation, PROCEEDINGS OF THE FLASH RADIOGRAPHY SYMPOSIUM ASNT Columbus, Ohio. 1977, 23-42
[4]	C. Ekdahl, IEEE Transactions on Plasma Science, 30:254-261(2002)
[5]	P. R. Vaidya, K. C. Mittal, A. S. Paithankar, Nuclear Instruments and Methods in Physics Research Section B:Beam Interactions with Materials and Atoms, 183:497-501(2001)
[6]	M. Gambaccini, P. Cardarelli, A. Taibi, A. Franconieri, G.Di Domenico, M. Marziani, R.C. Barna, L. Auditore, E. Morgana, D. Loria, A. Trifiro, M. Trimarchi, Nuclear Instruments and Methods in Physics Research B, 269(10):1157-1165(2011)
[7]	K. H. Muller, Measurement and characterization of X-ray spot size, Los Alamos National Laboratory Report LA-UR-89-1886(August 1989)
[8]	D. W. Forster, Radiographic spot size definitions, AWE Report HWH/9201/R8(January 1992)
[9]	C. Ekdahl, Journal of the Optical Society of America A, 28(12):2501-2509(2011)
[10]	J. J. Deng, B. N. Ding, H. C. Wang, G. S. Dai, N. A. Cheng, L. W. Zhang, K. Z. Zhang, Z. Y. Dai, J. S. Shi, High Power Laser and Particle Beams, 15(5):502-504(2003) (in Chinese)
[11]	B. N. Ding, J. J. Deng, H. C. Wang, N. A. Cheng, G. S. Dai, L. W. Zhang, C. J. Liu, W. W. Zhang, J. Li, K. Z. Zhang, High Energy Physics and Nuclear Physics, 29(6):604-610(2005) (in Chinese)
[12]	J. J. Shi, and M. Q. Qian, High Power Laser and Particle Beams, 4(1):119-126(1992) (in Chinese)
