Chinese Physics C > 2016, Vol. 40 > Issue(6): 066102 DOI: 10.1088/1674-1137/40/6/066102

Design of a high throughput electronics module for high energy physics experiments

1.
State Key Laboratory of Particle Detection and Electronics, Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
State Key Laboratory of Particle Detection and Electronics, Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
High-energy physics experiments enable us to explore and understand particle properties and interactions. An increase in luminosity in the accelerator, which allows us to study particles in higher energy ranges, demands faster data transmission and processing. Aimed at this, a high throughput uTCA-compliant electronics module, based on the latest FPGAs, has been designed. It contains 48 10.0 Gb/s optical fiber input channels and 24 10.0 Gb/s optical fiber output channels, supporting up to 480 Gb/s input bandwidth and 240 Gb/s output bandwidth. It complies with the uTCA standards, providing high speed data exchange capability and functioning as a compact and key module in a trigger and DAQ system for a large experiment. A reliable 10.0 Gb/s data transmission among two boards has been verified and one functionality that merges 6 1.6 Gb/s data channels into one single 10.0 Gb/s channel has been achieved. The hardware, firmware and software together with a performance evaluation are given in this paper.
- high throughput,
- concentration,
- trigger,
- DAQ,
- uTCA

References

[1]	ATLAS Collaboration, Phys. Lett. B, 716:1-29(2012)
[2]	CMS Collaboration, Phys Lett. B, 716:30-61(2012)
[3]	Acosta Darin and Ball Austin. CMS Technical Design Report for the Level-1 Trigger Upgrade. CERN-LHCC-2013-011, CMS-TDR-12:1, 2
[4]	ATLAS Collaboration, Technial Design Report for the Phase-I Upgrade of the ATLAS TDAQ System. CERN-LHCC-2013-018, ATLAS-TDR-023-2013:1-2
[5]	H Xu, ZA Liu et al, An ATCA-based high performance compute node for trigger and data acquisition in large experiments. Physics Procedia 37:1849-1854
[6]	Zhen-An Liu. Basic idea on Concentrator, CMS L1 Trigger Meeting (July 92013)
[7]	PICMG, Micro Telecommunications Computing Architecture Base Specification (July 6, 2006), p.1-8
[8]	PICMG. Advanced Mezzanine Card Base Specification (November 15, 2006), p.3-1
[9]	https://www.rogerscorp.com/documents/726/acm/RO4000-Laminates-Data-sheet.pdf, retrieved 1st October 2015
[10]	David E and Bockelman, IEEE Transactions on Microwave Theory and Techniques, 43:7(1995)
[11]	https://www.silabs.com/Support%20Documents/TechnicalD-ocs/Si5326.pdf, retrieved 1st October 2015
[12]	P. Moreira and T. Toifl, Gigabit Optical Link Transmitter Maual, Version 1.9(2005)
