Numerical simulation and design of a thermionic electron gun

Nijatie A

1.
Plasma Physics and Nuclear Fusion Research School, Nuclear Science and Technology Research Institute, AEOI, PO Box 14155-1339, Tehran, Iran

Abstract
HTML
Reference
Related

PDF

Abstract：
This paper reports the simulation of an electron gun. The effects on the beam quality of some parameters on the beam quality were studied and optimal choices were identified. It gives numerical beam qualities for a common electrostatic triode gun, and the dependencies on design parameters such as electrode geometries and bias voltages to these electrodes are shown. An electron beam of diameter 5 mm with energy of 5 keV was assumed for the simulation process. Some design parameters were identified as variable parameters in the presence of space charge. These parameters are the inclination angle of emission electrode, the applied voltage to the focusing electrode, the gap width between the emission electrode and the focusing electrode and the diameter of the focusing electrode. The triode extraction system is designed and optimized by using CST software(for Particle Beam Simulations). The physical design of the extraction system is given in this paper. From the simulation results, it is concluded that the inclination angle of the emission electrode is optimized at 22.5°, the applied voltage to the focusing electrode was optimized and found to be V _foc=-600 V, the optimal separation distance(gap between emission electrode and focusing electrode) is 4 mm, and the optimal diameter of the emission electrode is 14 mm. Initial results for these efforts aimed at emittance improvement are also be given.
- electron gun,
- electron beam trajectories,
- beam emittance and beam diameter,
- focusing voltage

References

[1]	N. Rykalin, A. Uglov, I. Zuev, A. Kokora, Laser and electron beam material processing handbook, Moscow:MIR Publishers;(1988)
[2]	S. Schiller, U. Heisig, S. Panzer, Electron beam technology, New York:Wiley; 1982
[3]	Proceedings of the 7-th International Conference on Electron Beam Technologies(EBT'2003) Varna, Bulgaria; 1e6 June(2003)
[4]	P. H. Ron, Bulletin of Indian Vacuum Society, 1(2):3(1998)
[5]	R. J. Bakish, Metals, 38:53(1986)
[6]	A. S. Gilmour, Jr., Principles of Traveling Wave Tubes,(Artech House, Inc., Norwood, 1941)
[7]	Alexander Wu Chao, Herbert Moser, Principle of Physics Charge Particle Acceleration, Part IX,(1996)
[8]	M. Sedlacek, Electron Physics of Vacuum and Gaseous Devices,(Wiley, New York, 1996)
[9]	C. J. Karzmark, Medical Electron Accelerators, Department of Radiation Oncology Stanford University School of Medicine(McGraw-Hill, New York, 1993)
[10]	CST PS manual,(2011)
[11]	A. Spetier, Focusing of charged particles, New York and London:Academic press,(1967)
[12]	P. Spadtke, The physics and technology of ion sources, New York:John Wiley,(2004)
