A novel method of encoded multiplexing readout for micro-pattern gas detectors

1.
State Key Laboratory of Particle Detection and Electronics, University of Science and Technology of China, Hefei 230026, China
2.
Department of Modern Physics, University of Science and Technology of China, Hefei 230026, China
3.
University of Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The requirement of a large number of electronic channels poses a big challenge to the further applications of Micro-pattern Gas Detectors(MPGDs). By using the redundancy that at least two neighboring strips record the signal of a particle, a novel method of encoded multiplexing readout for MPGDs is presented in this paper. The method offers a feasible and easily-extensible way of encoding and decoding, and can significantly reduce the number of readout channels. A verification test was carried out on a 5 cm×5 cm Thick Gas Electron Multiplier(THGEM) detector using a 8 keV Cu X-ray source with 100μ slit, where 166 strips were read out by 21 encoded readout channels. The test results show good linearity in its position response, and the spatial resolution root-mean-square(RMS) of the test system is about 260μ. This method has potential to build large area detectors and can be easily adapted to other detectors like MPGDs.
- micro-pattern gas detector,
- encoded multiplexing,
- readout method,
- position measurement

References

[1]	F. Sauli, Nucl. Instrum. Methods A, 386:531(1997)
[2]	A. Breskin et al, Nucl. Instrum. Methods A, 598:107(2009)
[3]	Y. Giomataris, Nucl. Instrum. Methods A, 376:29(1996)
[4]	M. Titov et al, Nucl. Instrum. Methods A, 581:25(2007)
[5]	G. Guedes et al, Nucl. Instrum. Methods A, 513:473(2003)
[6]	H. Wagner et al, Nucl. Instrum. Methods A, 523:287(2004)
[7]	M.Y. Dong et al, Chinese Physics C, 37(2):026002(2013)
[8]	Y. Zhou et al, Nucl. Instrum. Methods A, 604:71(2009)
[9]	S. Procureur et al, Nucl. Instrum. Methods A, 729:888(2013)
[10]	Q. Liu et al, Journal of Instrumentation, 8(11):C11008(2013)
[11]	J. Gross et al, Graph theory and its applications, CRC press, 2005
[12]	A. Balla et al, Nucl. Instrum. Methods A, 604:23(2009)
[13]	S. Chernenko et al, Journal of Instrumentation, 9(09):C09026(2014)
[14]	D. Neyret et al, Journal of Instrumentation, 4(12):P12004(2009)
[15]	A. Bressan et al, Nucl. Instrum. Methods. A, 425:254(1999)
