Beam size and position measurement based on logarithm processing algorithm in HLS Ⅱ

1.
National Synchrotron Radiation Laboratory, University of Science and Technology of China, Hefei 230029, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A logarithm processing algorithm to measure beam transverse size and position is proposed and preliminary experimental results in Hefei Light Source Ⅱ(HLS Ⅱ) are given. The algorithm is based on only 4 successive channels of 16 anode channels of multianode photomultiplier tube(MAPMT) R5900U-00-L16, which has typical rise time of 0.6 ns and effective area of 0.8×16 mm for a single anode channel. In the paper, we first elaborate the simulation results of the algorithm with and without channel inconsistency. Then we calibrate the channel inconsistency and verify the algorithm using a general current signal processor Libera Photon in a low-speed scheme. Finally we get turn-by-turn beam size and position and calculate the vertical tune in a high-speed scheme. The experimental results show that measured values fit well with simulation results after channel differences are calibrated, and the fractional part of the tune in vertical direction is 0.3628, which is very close to the nominal value 0.3621.
- logarithm processing algorithm,
- beam size and position,
- multianode photomultiplier tube,
- channel inconsistency

References

[1]	S. Sakanaka, T. Mitsuhashi, and T. Obina, Phys. Rev. ST Accel. Beams, 8:042801(2005)
[2]	T. Naito, Y. Hashimoto, H. Hayano et al, Beta-Matching and Damping Observation by SR Monitor at ATF DR, in Proceedings of EPAC 1998, Stockholm, Sweden, p. 1576
[3]	G. Kube, Review of Synchrotron Radiation based Diagnostics for Transverse Profile Measurements, in Proceedings of DIPAC 2007, Venice, Italy, p. 6
[4]	A. V. Bogomyagkov, V. F. Gurko, A. N. Zhuravlev et al, Rev. Sci. Instrum., 78:043305(2007)
[5]	M. Palmer, J. Dobbins, D. Hartill et al, Design and Implementation of an Electron and Positron Multibunch Turn-By-Turn Vertical Beam Profile Monitor in CESR, in Proceedings of PAC 2007, Albuquerque, New Mexico, p. 4081
[6]	K. Tang, J. G. Wang, B. G. Sun et al, High Power Laser and Particle Beams, 27:075101(2015)(in Chinese)
[7]	J. A. Clarke, A Review of Optical Diagnostics Techniques for Beam Profile Measurements, in Proceedings of EPAC 1994, Daresbury, UK, p. 1643
[8]	P. Leban, D. Tinta, and C. Pradervand, Photon Beam Position Measurements Using CVD Diamond based Beam Position Sensor and Libera Photon at Swiss Light Source, in Proceedings of IPAC 2010, Kyoto, Japan, p. 1077
[9]	C. C. Cheng, Y. Y. Xiao, B. G. Sun et al, A New Method of Acquiring Fast Beam Transversal Profile in the Storage Ring, in Proceedings of IPAC 2013, Shanghai, China, p. 556
