Smoothing analysis of HLSII storage ring magnets

1.
National Synchrotron Radiation Laboratory, University of Science and Technology of China, Hefei 230029, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Hefei Light Source (HLS) has been upgraded to improve the quality and stability of the synchrotron light, and the new facility is named HLSII. However, a final accurate adjustment is required to smooth the beam orbit after the initial instalment and alignment of the magnets. We implement a reliable smoothing method for the beam orbit of the HLSII storage ring. In addition to greatly smoothing and stabilizing the beam orbit, this method also doubles the work efficiency and significantly reduces the number of magnets adjusted and the range of the adjustments.
- smoothing,
- HLSII,
- curve fitting,
- least squares,
- iteration,
- relative error
