Drive laser system for the DC-SRF photoinjector at Peking University

1.
State Key Laboratory of Nuclear Physics and Technology, Institute of Heavy Ion Physics, Peking University, Beijing 100871, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Photoinjectors are widely used for linear accelerators as electron sources to generate high-brightness electron beams. The drive laser, which determines the timing structure and quality of the electron beam, is a crucial component of a photoinjector. A new drive laser system has been designed and constructed for the upgraded 3.5-cell DC-SRF photoinjector at Peking University. The drive laser system consists of a 1064 nm laser oscillator, a four-stage amplifier, second and fourth harmonic generators, an optical system to transfer the UV pulses to the photocathode, and a synchronization system. The drive laser system has been successfully applied during stable operation of the DC-SRF photoinjector and its performance meets requirements. A 266 nm laser with an average power close to 1 W can be delivered to illuminate the Cs ₂Te photocathode and the instability is less than 5% for long time operation. The design considerations for improving the UV laser quality, a detailed description of the laser system, and its performance are presented in this paper.
- drive laser,
- amplifier,
- harmonic generation,
- photoinjector

References

[1]	Ingo Will, Horst I. Templin, Siegfried Schreiber, and Wolfgang Sandner, Optics Express, 19: 23770 (2011)
[2]	S. Zhang, Drive Laser Systems for Electron Accelerators and Free-Electron-Lasers Based on Photocathode-Injector Energy-Recovery-Linac, in Proceedings of ERL09 (Ithaca, New York, 2009), WG110
[3]	K. Zhao, J. K. Hao, Y. L. Hu et al, Nucl. Instrum. Methods A, 475: 564 (2001)
[4]	J. K. Hao, X. Y. Lu, Y. T. Ding et al, Nucl. Instrum. Methods A, 557: 138 (2006)
[5]	X. Y. Lu, L. Lin, K. Zhao, and S. W. Zhang, HEP NP, 28: 8 (2004) (in Chinese)
[6]	E. J. Montgomery, D. W. Feldman, Z. Pan et al, in Proceedings of PAC07, (Albuquerque, New Mexico, 2007), p.1206
[7]	F. Zhu, S.W. Quan, J.K. Hao et al, Status of the DC-SRF Photoinjector for PKU-SETF, in Proceedings of SRF2011 (Chicago, IL, 2011), p.973
[8]	G. D. Boyd, D. A. Kleinman, J. Appl. Phys., 39: 3597 (1968)
[9]	C. Droz, H. Kouta, and Y. Kuwano., Optical Review, 6: 97 (1999)
[10]	J. Friebe, K. Moldenhauer, E. M. Rasel et al, Opt. Comm., 261: 300 (2006)
[11]	T. Onda, M. Shinnosuke, and I. Shoji, A New Walk-Off Compensating BBO Device with Thinner-Plae-Stacked Structrue Fabricated by Room-Temperature Bonding, in Proccedings Nonlinear Optics 2013 (Kohala Coast, Hawaii, 2013), p.NTu3B.1
