Design of a C-band relativistic extended interaction klystronwith coaxial output cavity

Abstract
HTML
Reference
Related

PDF

Abstract：
In order to overcome the disadvantages of conventional high frequency relativistic klystron amplifiers in power capability and RF conversion efficiency, a C-band relativistic extended interaction klystron amplifier with coaxial output cavity is designed with the aid of PIC code MAGIC. In the device, disk-loaded cavities are introduced in the input and intermediate cavity to increase the beam modulation depth, and a coaxial disk-loaded cavity is employed in the output cavity to enhance the RF conversion efficiency. In PIC simulation, when the beam voltage is 680 kV and current is 4 kA, the device can generate 1.11 GW output power at 5.64 GHz with an efficiency of 40.8%.
