Chinese Physics C > 2015, Vol. 39 > Issue(5): 056003 DOI: 10.1088/1674-1137/39/5/056003

A cosmic ray test platform based on high time resolution MRPC technology

Abstract
HTML
Reference
Related

PDF

Abstract：
In order to test the performance of detector prototypes in a laboratory environment, we design and build a large area (90 cm×52 cm) test platform for cosmic rays based on a well-designed Multi-gap Resistive Plate Chamber (MRPC) with excellent time resolution and a high detection efficiency for minimum ionizing particles. The time resolution of the MRPC module used is tested to be ～80 ps, and the position resolution along the strip is ～5 mm, while the position resolution perpendicular to the strip is ～12.7 mm. The platform constructed by four MRPC modules can be used for tracking cosmic rays with a spatial resolution of ～6.3 mm, and provide a reference time ～40 ps.

References

[1]

Williams M C S, Cerron E et al. Nucl. Instrum. Methods A, 1999, 434: 362-372[2] SUN Y J et al. Nucl. Instrum. Methods A, 2008, 593: 307-313[3] SUN Yong-Jie et al. Chinese Physics C, 2011, 35(9): 838-843[4] YANG C, HUANG X J, DU C M et al. arXiv:1402.1078[5] Anghinolfi F, Jarron P, Martemiyanov A N et al. Nucl. Instrum. Methods A, 2004, 533: 183[6] Anghinolfi F, Jarron P, Krummenacher F et al. NINO, An Ultra-fast, Low-power, Front-end Amplifier Discriminator for the Time-Of-Flight Experiment in ALICE. Presented at 2003 Nuclear Science Symposium, Portland, Oregon[7] ALICE collaboration. Addendum to the Technical Design Report of the Time-Of-Flight System, CERN/LHCC/2002-16[8] LI Cheng et al. HEP NP, 2006, 30(7): 660 (in Chinese)
