Design of a high flux VUV beamline for low energy photons

Abstract
HTML
Reference
Related

PDF

Abstract：
A VUV beamline at the Shanghai Synchrotron Radiation Facility (SSRF) for angle-resolved photoelectron spectroscopy (ARPES) measurements is designed. To increase the resolution and bulk sensitivity, a photon energy as low as 7 eV is desired. Because the reflectivity for p-polarized photons strongly decreases when the photon energy is below 30 eV, the design of a high flux beamline for low energy VUV photons is a challenge. This work shows a variable including angle Varied Line-space Plane-Grating Monochromator (VLPGM) with varied grating depth (VGD) which can achieve both high resolution and high flux with broad energy coverage.

References

[1]

Brundle, C. R. J. Vacuum Sci. Technol., 1974, 11: 212-224[2] QIAO S et al. Rev. Sci. Instrum., 2009, 80: 085108[3] Onuki H, Elleaume P. Undulators, Wigglers and Their Applications. London: Taylor and Francis, 2003. 79[4] CHEN C T. Nucl. Instrum. Methods A, 1987, 256: 595-604[5] Follath R, Sent F, Gudat W J. Synchrotron Rad., 1998, 5: 769-771[6] Strocov V N et al. J. Synchrotron Rad., 2010, 17: 631-643[7] YAN Y, Shigemasa E, Yagishita A J. Synchrotron Rad., 1998, 5: 246-251[8] Amemiya K, Ohta T J. Synchrotron Rad., 2004, 11: 171-176[9] Schafers F, Abramsohn D, Krumrey M. REFLEC, a Program to Calculate VUV/X-ray Optical Elements and Synchrotron Radiation Beamline. BESSY Preprint, 2002[10] Neviére M, Vincent P et al. Appl. Optics, 1978, 17: 843-845[11] Schafers F. Ray, the Bessy Raytrace Program to Calculate Synchrotron Radiation Beamlines. BESSY Preprint, 1996
