Chinese Physics C > 2015, Vol. 39 > Issue(4): 046001 DOI: 10.1088/1674-1137/39/4/046001

A large-area GEM detector using a novel self-stretching technique

Abstract
HTML
Reference
Related

PDF

Abstract：
A Gas Electron Multiplier (GEM) detector with an effective area of 300 mm×300 mm has been constructed using a novel self-stretching technique, which allows a highly flexible and efficient GEM detector assembly free of glue or spacers. This makes the re-opening and repair of the GEM detectors possible and significantly reduces the scrap rate in the mass production of large-area GEM detectors. With the technique, the assembly time can be limited to a few hours, a factor of ten improvement compared to that using gluing techniques. The details of design and assembly procedure of the 300 mm×300 mm GEM detector are described in this paper. This detector was tested with 8 keV X-rays for the effective gain, energy resolution and performance uniformity. The results show that the typical energy resolution is 20% at an effective gain of about 10^4, with fairly good uniformity.

References

[1]

Sauli F. Nucl. Instrum. Methods A, 1997, 386: 531[2] Bachmann S et al. Nucl. Instrum. Methods A, 1999, 438: 376[3] LAI Yong-Fang, LI Yu-Lan, LI Yuan-Jing et al. HEP NP, 2006, 30(08): 767-770 (in Chinese)[4] AN Shao-Hui, LI Cheng, XU Zi-Zong et al. HEP NP, 2004, 28(04): 412-416 (in Chinese)[5] De Oliveira R. Large size GEM Detectors in TE/MPE/EM, 2011[6] Buttner C et al. Nucl. Instrum. Methods A, 1998, 409: 79[7] Bachmann S et al. Nucl. Instrum. Methods A, 1999, 443: 464[8] Villa M et al. Nucl. Instrum. Methods A, 2011, 628: 182[9] The Super Bigbite Collaboration, Progress Report on the Super Bigbite Spectrometer, 2011[10] The KLOE-2 collaboration. Technical Design Report of the Inner Tracker for the KLOE-2 Experiment. 2010[11] Abbaneo D et al. RD51-NOTE-2012-12. 2012[12] Noto F et al. Jlab12-Group GEM, Meccanica Tracker. 2011[13] Staib M et al. RD51-NOTE-2011-004. 2011[14] Franconi L et al. Status of No-stretch No-spacer GEM Assembly, the NS2 Technique Method and Experiment Results. 2012[15] Bencivenni G et al. The LHCb Experience with the Assembly of the GEM, GEM Training Session - CERN. 16, Feb. 2009[16] Armaingaud C. Gain Uniformity Tests on Full Scale Triple GEM Detectors for CMS High Eta Upgrade. MPGD 2013 11th RD51 Collaboration Meeting, 1-6 July, 2013
