Chinese Physics C > 2015, Vol. 39 > Issue(2): 026101 DOI: 10.1088/1674-1137/39/2/026101

A high-precision multi-channel TAC and QAC module for the neutron detection wall

Abstract
HTML
Reference
Related

PDF

Abstract：
A single width NIM module that includes eight channels of the time-to-amplitude converter (TAC) and the charge-to-amplitude converter (QAC) is introduced in the paper, which is designed for the large neutron wall detector to measure charge (energy) and time interval simultaneously. The module adopts a high precision gated integration circuit to realize TAC and QAC. The input range of TAC is from 30 ns to 1 μs, and the input range of QAC is from 40 pC to 600 pC. The linearity error of TAC is lower than 1.28%, and the time resolution of TAC is less than 0.871%. The linearity error of QAC is lower than 0.81%, and the resolution of QAC is better than 0.936%.

References

[1]

YU Yu-Hong, XU Hua-Gen, XU Hu-Shan et al. Chin. Phys. C, 2009, 33(9): 781-784[2] YU Yu-Hong, XU Hua-Gen, XU Hu-Shan et al. Chin. Phys. C, 2009, 33(7): 557-561[3] Karsten K, Hardel H, Schulze R et al. IEEE Trans. Nucl. Sci., 2005, 52(3): 745-747[4] Ciobanu M, Schüttauf A, Cordier E et al. IEEE Trans. Nucl. Sci., 2007, 54(4): 1201-1206[5] Inaba S, Takamatsu K, Ikeda H et al. Nucl. Instrum. Methods Phys. Res. A, 2000, 455: 683-697[6] Inaba S, Tsuru T, Takamatsu K et al. Nucl. Instrum. Methods Phys. Res. A, 2000, 442: 309-315
