Chinese Physics C > 2015, Vol. 39 > Issue(12): 129001 DOI: 10.1088/1674-1137/39/12/129001

Design of a conduction-cooled 4 T superconducting racetrack for a multi-field coupling measurement system

Abstract
HTML
Reference
Related

PDF

Abstract：
A conduction-cooled superconducting magnet producing a transverse field of 4 T has been designed for a new generation multi-field coupling measurement system, which will be used to study the mechanical behavior of superconducting samples at cryogenic temperatures and intense magnetic fields. A compact cryostat with a two-stage GM cryocooler is designed and manufactured for the superconducting magnet. The magnet is composed of a pair of flat racetrack coils wound by NbTi/Cu superconducting composite wires, a copper and stainless steel combinational former and two Bi ₂Sr ₂CaCu ₂O _ysuperconducting current leads. The two coils are connected in series and can be powered with a single power supply. In order to support the high stress and attain uniform thermal distribution in the superconducting magnet, a detailed finite element (FE) analysis has been performed. The results indicate that in the operating status the designed magnet system can sufficiently bear the electromagnetic forces and has a uniform temperature distribution.
- conduction-cooled,
- superconducting magnet,
- multi-field coupling measurement system,
- mechanical and thermal analysis

References

[1]	GUAN Ming-Zhi, WANG Xing-Zhe, MA Li-Zhen et al. Journal of Superconductivity and Novel Magnetism, 2012, 26: 2361-2368
[2]	Elen J D, Franken W M P, Horvath I et al. IEEE Trans. Magnetics, 1981, 17(1): 490-493
[3]	Bruzzone P, Anghel A, Fuchs A et al. IEEE Trans. Appl. Supercon., 2002, 12(1): 520-523
[4]	Verweij A. The 10 T dipole magnet of the FRESCA facility: An Overview of 6 Years of Operation, Magnets and Superconductors Group AT-MAS, Internal Note, 2005: 2005-04
[5]	Ulbricht A. Fusion Engineering and Design, 2003, 66-68: 103-118
[6]	Milanese A. A Method to Transfer Distributed Lorentz Forces in 3D to a Finite Element Mechanical Model, CERN-ATS-Note. 2011
[7]	GUO Bei-Lei, MA Li-Zhen et al. IEEE Trans. Appl. Supercon. 2010, 20(3): 1781-1784
[8]	GUAN M Z, WANG X Z, ZHOU Y H. Cryogenic Temperture. IEEE Trans. Appl. Supercon., 2012, 22(6): 8401106
[9]	SONG Xiao-Wei, DAI Yin-Ming, WANG Qiu-Liang et al. Cryogenics & Superconductivity, 2009, 38(3): 1-5
