Chinese Physics C > 2015, Vol. 39 > Issue(10): 106101 DOI: 10.1088/1674-1137/39/10/106101

Waveform timing performance of a 5 GS/s fast pulsesampling module with DRS4

Abstract
HTML
Reference
Related

PDF

Abstract：
We first clarify timing issues of non-uniform sampling intervals regarding a 5 GS/s fast pulse sampling module with DRS4. A calibration strategy is proposed, and as a result, the waveform timing performance is improved to below 10 ps RMS. We then further evaluate waveform-timing performance of the module by comparing with a 10 GS/s oscilloscope in a setup with plastic scintillators and fast PMTs. Different waveform timing algorithms are employed for analysis, and the module shows comparable timing performance with that of the oscilloscope.
