Mechanical design and analysis of a low beta squeezedhalf-wave resonator

Abstract
HTML
Reference
Related

PDF

Abstract：
A superconducting squeezed type half-wave resonator (HWR) of β=0.09 has been developed at the Institute of Modern Physics, Lanzhou. In this paper, a basic design is presented for the stiffening structure for the detuning effect caused by helium pressure and Lorentz force. The mechanical modal analysis has been investigated the with finite element method (FEM). Based on these considerations, a new stiffening structure is proposed for the HWR cavity. The computation results concerning the frequency shift show that the low beta HWR cavity with new stiffening structure has low frequency sensitivity coefficient d f/d pand Lorentz force detuning coefficient K _L, and stable mechanical properties.
