Chinese Physics C > 2014, Vol. 38 > Issue(8): 086004 DOI: 10.1088/1674-1137/38/8/086004

Proton irradiation effect on SCDs

Abstract
HTML
Reference
Related

PDF

Abstract：
The Low Energy X-ray Telescope is one of the main payloads on the Hard X-ray Modulation Telescope satellite. Swept charge devices (SCDs) are selected as detectors for the Low Energy X-ray Telescope. As SCDs are sensitive to proton irradiation, irradiation tests were carried out on the HI-13 accelerator at the China Institute of Atomic Energy. The beam energy was measured to be 10 MeV at the SCD. The proton fluence delivered to the SCD was 3×10 ⁸protons cm ²over two hours. By comparing the performance before and after irradiation, it is concluded that proton irradiation affects both the dark current and the charge transfer inefficiency of the SCD. The energy resolution of the proton-irradiated SCD is 212 eV@5.9 keV at -60℃, while it before irradiated is 134 eV. Moreover, better performance can be reached by lowering the operating temperature of the SCD in orbit.

References

[1]

LI T P. Nuclear Physics B Proceedings Supplements, 2007, 166: 131-139[2] Holland A D. Pool P. Proc. of SPIE, 2008, 7021: 702117-1[3] Lowe B G. Holland A D, et al. Nuclear Instruments and Methods in Physics Research A，2001, 458: 568-579[4] Smith P H, Gow J P D et al. Proc. of SPIE, 2012, 8453: 84530R-1[5] Janesick J R. Scientific Charge-Coupled Devices, Bellingham, Washington: SPIE Press, 2001. 387-390[6] WANG Yu-Sa, CHEN Yong, XU Yu-Peng et al. Chinese Physics C (HEP NP), 2009, 33: 1-5[7] Mazziotta M N. Nuclear Instruments and Methods in Physics Research A, 2008, 584: 436-439[8] WANG Yu-Sa, YANG Yan-Ji, CHEN Yong et al. Chinese Physics C, 2014, 38: 066001
