Development of a 325 MHzβ=0.12 superconducting single spoke cavity for China-ADS

Abstract
HTML
Reference
Related

PDF

Abstract：
Twelve very low Beta superconducting single spoke cavities, whose Beta is only 0.12 (Spoke012) when operating at 325 MHz, are adopted in Injector I for China-ADS linac. This type of spoke cavity is believed to be one of the key challenges for its very low geometric Beta. So far, in collaboration with Peking University and Harbin Institute of Technology, IHEP has successfully designed, fabricated, and tested the Spoke012 prototype cavity. This paper presents the details of the design, fabrication and test results for Spoke012 prototype cavity.
