Current leads for superconducting magnets of ADS injector Ⅰ

Abstract
HTML
Reference
Related

PDF

Abstract：
In an ADS injector Ⅰ, there are five superconducting magnets in each cryomodule. Each superconducting magnet contains a solenoid magnet, a horizontal dipole corrector (HDC), and a vertical dipole corrector (VDC). Six current leads will be required to power the electrical circuits, from room temperature to the 2.1 K liquid helium bath: two leads carry 100 A current for the solenoid magnet while the other four carry 12 A for the HDC and the VDC. This paper presents the principle of current lead optimization, which includes the cooling methods, the choice of material and structure, and the issues for current lead integration.

References

[1]

Zeller A F et al. IEEE Transaction on Applied Superconductivity, 2002, 12: 329[2] PENG Quan-Ling, WANG Bing, CHEN Yuan et al. Chinese Physics C (HEP NP), to be published[3] Wilson M N, Superconducting Magnet. Oxford: Clarendon press, 1997. 256[4] Barrarino A. Current Leads for the LHC Magnet System. IEEE Transaction on Applied Superconductivity, 2002, 12: 1275
