Chinese Physics C > 2014, Vol. 38 > Issue(4): 046203 DOI: 10.1088/1674-1137/38/4/046203

Implementation of the direct demodulation method for natural gamma ray spectral logging

Abstract
HTML
Reference
Related

PDF

Abstract：
Spectrum analysis of natural gamma ray spectral logging (SGR) data is a critical part of surface information processing systems. Due to the low resolution, which is an inherent weakness of SGR, and the low signal-to-noise ratio problem of logging measurements, SGR is usually treated with a low confidence level. The Direct Demodulation (DD) method is an advanced technique to solve modulation equations interactively under physical constraints. It has higher sensitivity and spatial resolution than the traditional methods and can effectively suppress the logging noise. Based on standard count rate spectral data obtained from the China Offshore Oil Logging Company SGR Calibration Facility, this paper presents the application of the DD method to gamma-ray logging. The results are compared with four traditional algorithmic methods, showing that the DD method is a credible choice, with higher sensitivity and higher spatial resolution in gamma-ray log interpretation. The Point-Spread-Function of the Shengli Oil Logging Company's natural gamma ray spectroscopy instrument is obtained for the first time. The quantities of various radionuclides in their calibration pits are also obtained. The DD method was applied successfully to gamma-ray logging, offering a new option for SGR logging algorithm selection.

References

[1]

HUANG Long-Ji, SHOU Xiang-Yun, WANG Rui-Ping. Natural Gamma Ray Spectrum Logging Principle and Application．Beijing: Oil Industry Press, 1995. 176-195[2] HUANG Long-Ji. Nuclear Logging Principles．Dongying: Oil University Press, 2000[3] GUO Ying-Wen. World Well Logging Technology, 2008, 6: 49-51[4] LI T P, WU M．In: Astronomical Data Analysis Software Systems I. eds Worrall D M, Biemesderfer C, Barnes J. BookCrafters, Inc., 1992. 229[5] LI Ti-Pei, WU Mei. ACTA Astrophysica Sinica, 1993, 17(3): 263-270[6] LI Ti-Pei. Exploration of Nature, 1999, 18(67): 45-47[7] LI Ti-Pei, WU Mei, LU Zhu-Guo et al. ACTA Astronomica Sinica, 1994, 35(1): 105-108[8] ZHANG Shu, LI Ti-Pei, WU Mei. ACTA Astronomica Sinica, 1997, 17(3): 263-270[9] LU Fang-Jun, LI Ti-Pei, WU Mei et al. ACTA Astronomica Sinica, 1997, 38(1): 56-65[10] LIU Li. Nuclear Techniques, 1998, 21(3): 188-192[11] SUN Fei, XUE Ping, GAO Jian-Song et al. ACTA Optica Sinica, 2000, 20(8): 1043-1046[12] ZHAO Fa-Zhan, MAO Shang-Ming, WEI Zhong-Liang et al. World Well Logging Technology, 2004, 19(2): 47-50[13] SUN Jian-Meng, LI Zhao-Cheng. Journal of the University of Petroleum, 1999, 23(4): 29-32[14] WANG Zhu-Wen, LIU Jing-Hua, HUANG Qian. Lithologic Reservoirs, 2007, 19(2): 108-111[15] HUANG Qian, LIU Jing-Hua, WANG Zhu-Wen. Journal of Jilin U niversity (Earth Science Edit ion), 2007, 37(Supp.): 143-150[16] WANG Qian. Geophysical Prospecting for Petroleum, 2004, 43(5): 504-507[17] HUANG Kai, XU Qun-Zhou, YANG Xiao-Hai et al. Xinjiang Petroleum Geology, 1997, 9(3): 212-216[18] PANG Ju-Feng, CHI Yun-Peng, ZHONG Zhen-Wei. Modern Nuclear Logging Technology and Equipment. Beijing: Oil Industry Press, 1998[19] HUANG Long-Ji, HU Qing-Dong. ACTA Geophysica Sinica, 1997, 40(2): 272-278[20] Grau J A,Schweitzer J S. Geophys, 1987, 1(2): 157-165[21] REN Ai-Ge. The Study of Spectral Analysis of Natural Gamma Ray Spectralog． Dongying: China University of Petroleum Books Archives, 2007
