Chinese Physics C > 2014, Vol. 38 > Issue(4): 046202 DOI: 10.1088/1674-1137/38/4/046202

Automatic calibration method of voxel size for cone-beam 3D-CT scanning system

Abstract
HTML
Reference
Related

PDF

Abstract：
For a cone-beam three-dimensional computed tomography (3D-CT) scanning system, voxel size is an important indicator to guarantee the accuracy of data analysis and feature measurement based on 3D-CT images. Meanwhile, the voxel size changes with the movement of the rotary stage along X-ray direction. In order to realize the automatic calibration of the voxel size, a new and easily-implemented method is proposed. According to this method, several projections of a spherical phantom are captured at different imaging positions and the corresponding voxel size values are calculated by non-linear least-square fitting. Through these interpolation values, a linear equation is obtained that reflects the relationship between the voxel size and the rotary stage translation distance from its nominal zero position. Finally, the linear equation is imported into the calibration module of the 3D-CT scanning system. When the rotary stage is moving along X-ray direction, the accurate value of the voxel size is dynamically exported. The experimental results prove that this method meets the requirements of the actual CT scanning system, and has virtues of easy implementation and high accuracy.

References

[1]

Erik L, Ritman. Annu. Rev. Biomed. Eng., 2004, 6: 185-208[2] Lee Sang Chul, Kim Ho Kyung, Chun In Kon et al. Phys. Med. Biol., 2003, 48: 4173-4185[3] Altunbas M, Shaw C, Chen L. Medical Physics, 2006, 33: 2287-2295[4] Sidky E Y, PAN X. Phys. Med. Biol., 2008, 53: 4777-4807[5] CHEN G H, TANG J, LENG S. Med. Phys., 2008, 35: 660-663[6] PAN X, Sidky E Y, Vannier M. Inverse Probl., 2009, 25: 123009[7] Nagarkar V V, Gordon J S, Vasile S et al. IEEE Trans. on Nucl. Sci., 1996, 43: 1559-1563[8] Maret D, Telmon N, Peters O A. Dento maxillo facial radiology, 2012, 41: 649-655[9] Tanimoto H, Ara Y. Oral Radiology, 2009, 25: 149-513[10] Bechara Boulos, McMahan C Alex, Moore William S. Oral Surgery SURGERY Oral Medicine Oral Pathology Oral Radiology, 2012, 214: 658-665[11] YANG Min, GAO Haidong, LI Xing-Dong et al. NDTE International, 2012, 46: 48-54[12] YANG Min, JIN Xu-Ling, LI Bao-Lei. Chin. Phys. C (HEP NP). 2010, 34: 1665-1670[13] Antoni Buades, Bartomeu Coll, Jean-Michel Morel. Int. J. Comput Vis., 2008, 76: 123-139[14] YANG Min, YANG Yi-Min, WANG Chang-Sui. Science and Technology, 2011, 19: 333-343[15] Lyvers E P, Mitchell O R. IEEE Tans. on Pattern Analysis and Machine Intelligence, 1989, 11: 1293-1308[16] YAN Bei, WANG Bin, LI Yuan. Journal of Beijing University of Aeronautics and Astronautics, 2008, 34: 295-298 (in Chinese)[17] Ryniewicz A, Accuray. Metrol. Meas. Syst., 2010, 17: 382-386
