Chinese Physics C > 2014, Vol. 38 > Issue(3): 037001 DOI: 10.1088/1674-1137/38/3/037001

Design of SC solenoid with high homogeneity

Abstract
HTML
Reference
Related

PDF

Abstract：
A novel kind of SC (superconducting) solenoid coil is designed to satisfy the homogeneity requirement of the magnetic field. In this paper, we first calculate the current density distribution of the solenoid coil section through the linear programming method. Then a traditional solenoid and a nonrectangular section solenoid are designed to produce a central field up to 7 T with a homogeneity to the greatest extent. After comparision of the two solenoid coils designed in magnet field quality, fabrication cost and other aspects, the new design of the nonrectangular section of a solenoid coil can be realized through improving the techniques of framework fabrication and winding. Finally, the outlook and error analysis of this kind of SC magnet coil are also discussed briefly.

References

[1]

WANG Qiu-Liang, XU Guo-Xin, DAI Yin-Ming et al. IEEE Transactions on Applied Superconductivity, 2009, 19: 2289-2292[2] Matthew Ian Hollister. The SCUBA-2 Instrument: An Application of Large-Format Superconducting Bolometer Arrays for Submillimetre Astronomy. Jan-2009, The university of Edinburgh[3] WU Wei, HE Yuan, MA Li-Zhen et al. Chinese Physics C (HEP NP), 2009, 34: 978[4] Joon-Han Bae, Ki-Deok Sim, Rock-Kil Ko et al. The fabrication of superconducting magnet for MRI Physica C, 2002, 372: 1342[5] YANG Xiao-Liang, MA Li-Zhen, WU Wei et al. Chinese Physics C (HEP NP), 2012, 36(9): 886-890[6] WANG Qiu-Liang, DAI Ying-Ming, ZHAO Bao-Zhi et al. Cryogenics, 2007, 47: 374[7] Martin N. Wilson. Superconducting Magnets. Clarendon Press, Oxford, 1983. 26
