Chinese Physics C > 2014, Vol. 38 > Issue(10): 107008 DOI: 10.1088/1674-1137/38/10/107008

A permanent magnet electron beam spread system used fora low energy electron irradiation accelerator

Abstract
HTML
Reference
Related

PDF

Abstract：
The development of irradiation processing industry brings about various types of irradiation objects and expands the irradiation requirements for better uniformity and larger areas. This paper proposes an innovative design of a permanent magnet electron beam spread system. By clarifying its operation principles, the author verifies the feasibility of its application in irradiation accelerators for industrial use with the examples of its application in electron accelerators with energy ranging from 300 keV to 1 MeV. Based on the finite element analyses of electromagnetic fields and the charged particle dynamics, the author also conducts a simulation of electron dynamics in magnetic field on a computer. The results indicate that compared with the traditional electron beam scanning system, this system boosts the advantages of a larger spread area, non-power supply, simple structure and low cost, etc., which means it is not only suitable for the irradiation of objects with the shape of tubes, strips and panels, but can also achieve a desirable irradiation performance on irregular constructed objects of large size.

References

[1]

Chmielewski A G, Haji-Saeid M. Radiation Physics and Chemistry, 2014, 71(1-2): 17-21[2] Emerging Applications of Radiation Processing. IAEA-TECDOC-1386, April, 2003[3] ZHENG Shu-Xin, TANG Chuan-Xiang et al. Chinese Physics C, 2008, 32(3): 228[4] LIU Hua-Chang, WANG Xiu-Long, FU Shi-Nian. High Energy Physics and Nuclear Physics, 2006, 30(6): 581 (in Chinese)[5] WANG Xiang-Qi, XU Yu-Cun et al. Nuclear Techniques, 2008, 31(6): 441; YANG Jun, LI Dong et al. Calculation and Design of a High Voltage Electron Accelerator. Proceedings of IPAC'10, Kyoto, Japan, MOPEB074[6] Sanelli C, Voelker F et al. Specification of Power Supplies for Eight Scanning Dipole Magnets of the CNAO Project. CNAO internal Spec., CNASP-DF-007WXX-03018[7] FENG De-Ren, WANG Xiang-Qi et al. High Power Laser and Particle Beams, 2008, 20(4) 593-596 (in Chinese)[8] REN Xiu-Yan, LU Yu-Zhu. Atomic Energy Science and Technology, 2011, 45(7): 868 (in Chinese)[9] According to a Meeting with Xianghua Zhang, a senior engineer and the director of Wuxi EL Pont Group, held in Huazhong University of Sicence and Technology. WUHAN, at July, 2013, 18[10] MO Yan, ZHANG Xing-Bao, ZHANG Ya-Qun. J. Radiat. Res. Radiat. Process., 2006, 24(1): 59-60[11] YUAN Qin-Liang, WANG You-Zhi et al. High Energy Physics and Nuclear Physics, 1987, 11(1): 15 (in Chinese)[12] Novitski I, Zlobin A V. IEEE Trans. Appl. Supercond., 2007, 17(2): 1059-1062[13] Bogacki P, Shampine L F. Appl. Math. Lett., 1989, 2: 1-9[14] Luna H B. Luna Nuclear Instruments and Methods in Physics research A, 1989, 285: 349[15] YANG Jian-Jun, ZHANG Tian-Jue et al. High Energy Physics and Nuclear Physics, 2007, 31(8): 769 (in Chinese)
