Chinese Physics C > 2014, Vol. 38 > Issue(10): 106101 DOI: 10.1088/1674-1137/38/10/106101

Development of a multi-channel readout ASIC for a fast neutron spectrometer based on GEM-TPC

Abstract
HTML
Reference
Related

PDF

Abstract：
A multi-channel front-end ASIC has been developed for a fast neutron spectrometer based on Gas Electron Multiplier (GEM)-Time Projection Chamber (TPC). Charge Amplifier and Shaping Amplifier for GEM (CASAGEM) integrates 16+1 channels: 16 channels for anodes and 1 channel for cathode. The gain and the shaping time are adjustable from 2 to 40 mV/fC and from 20 to 80 ns, respectively. The prototype ASIC is fabricated in 0.35 μ CMOS process. An evaluation Print Circuit Board (PCB) was also developed for chip tests. In total 20 chips have been tested. The integrated nonlinearity is less than 1%. The equivalent noise electrons is less than 2000e when the input capacitor is 50 pF. The time jitter is less than 1 ns. The design and the test results are presented in the paper.
