Chinese Physics C > 2013, Vol. 37 > Issue(7): 078001 DOI: 10.1088/1674-1137/37/7/078001

Multilayer-based soft X-ray polarimeter at the Beijing Synchrotron Radiation Facility

Abstract
HTML
Reference
Related

PDF

Abstract：
A compact high precision eight-axis automatism and two-axis manual soft-ray polarimeter with a multilayer has been designed, constructed, and installed in 3W1B at the Beijing Synchrotron Radiation Facility (BSRF). Four operational modes in the same device, which are double-reflection, double-transmission, front-reflection-behind-transmission and front-transmission-behind-reflection, have been realized. It can be used for the polarization analysis of synchrotron radiation. It also can be used to characterize the polarization properties of the optical elements in the soft X-ray energy range. Some experiments with Mo/Si and Cr/C multilayers have been performed by using this polarimeter with good results obtained.

References

[1]

Eimüller T, Kato T, Mizuno T et al. Appl. Phys. Lett., 2004, 85(12): 2310[2] Scholl A, Sthr J, Lüning J et al. Scinece, 2000, 287: 1014-1016[3] Mertins H-Ch, Schfers F, Cann X Le et al. Phys. Rev. B, 2000, 61(2): R874-R877[4] Guedes I, Grimsditch M, Metlushko V et al. Phys. Rev. B., 2003, 67(2): 024428[5] Zaharko O, Mertins H-Ch, Schfers F. Nucl. Instrum. Methods A, 2001, 467-468: 1419-1422[6] Kortright J B, Rice M, Kim S K et al. J. Magn. Magn. Mater., 1999, 191(1-2): 79-89[7] Kimura H, Yamamoto M, Yanagihara M et al. Rev. Sci. Instrum., 1992, 63(1): 1379-1380[8] Haga T, Utsumi Y, Itabashi S SPIE Conference on X-ray and Ultraviolet Spectroscopy, 1998, 3443: 117-119[9] Schfers F, Mertins H-Ch, Gaupp A S et al. Appl. Opt., 1999, 38(19): 4074-4088[10] WANG H, Dhesi S S, Maccherozzi F et al. Rev. Sci. Instrum., 2011, 82(12): 123301[11] Gluskin E S, Gaponov S V, Dhez P et al. Nucl. Instrum. Methods A, 1986, 246(1-3): 394-396[12] Kortright J B. Proc. SPIE, 1993, 2010: 160-167[13] CUI Ming-Qi, CUI Cong-Wu, ZHAO Yi-Dong et al. Atomic Energy Science and Technology, 1998, 32(6): 492-498 (in Chinese)[14] SUN Li-Juan, CUI Ming-Qi, ZHU Jie et al. HEP NP, 2007, 31(4): 400-404 (in Chinese)[15] YAN Fen, CUI Ming-Qi, CHEN Kai et al. Acta. Phys. Sin., 2008, 57(5): 2865-2865 (in Chinese)[16] CHEN Kai, CUI Ming-Qi, YAN Fen et al. Chin. Phys. Lett., 2008, 25(3): 1110-1112
