Design and development of the CSNS ion source control system

Abstract
HTML
Reference
Related

PDF

Abstract：
Now that the CSNS ion source test stand has been stably working for years, an online control system for the CSNS ion source which aims to be more stable and reliable is now under development. F3RP61-2L, a new PLC CPU module running an embedded Linux system, is introduced to the system as an IOC, to function together with the I/O modules of FA-M3 PLC on the PLC-bus. The adoption of the new IOC not only simplifies the architecture of the control system, but also improves the data transmission speed. In this paper, the design and development of the supervisory and control system for the CSNS ion source are described.

References

[1]	LU Y H, LI G, OUYANG H F et al. Chinese Physics C (HEP NP), 2010, 34(12): 1883-1886[2] Odagiri J, Araki S, Furukawa K et al. Proceedings of ICALEPCS, Japan, 2009. 916-918[3] Koolwal Kushal, RTLWS11, Germany. 2009
