E-field measurement of a pulse line ion accelerator

Abstract
HTML
Reference
Related

PDF

Abstract：
The E-field of pulse line ion accelerator (PLIA) is unique with high frequency (～ MHz), large magnitude (～ MV/m), and limited measuring space (～ cm). The integrated optical E-field sensor (IOES) has remarkable advantages and has been used for PLIA E-field measurement. Firstly, the transfer function of the IOES has been calibrated to ensure measurement accuracy. The time-domain response illustrates that the sensor has a fast dynamic performance to effectively follow a 4 ns rising edge. Then, the E-field distribution along the axis and near the insulator surface of the PLIA was measured, showing that propagation of the E-field is almost lossless and the E-field near the insulation surface is about 1.1 times larger than that along the axis, which is in accordance with the simulation result.

References

[1]

Briggs R J. Phys. Rev. ST Accel. Beams., 2006, 9(6): 060401[2] Colemana J E, Friedmanb A, Waldron W L et al. Nucl. Instrum. Methods Phys. Res., Sect. A, 2007, 577: 197-202[3] ZENG Rong, WANG Bo, YU Zhan-Qing et al. IEEE Trans. Dielectr. Electr. Insul., 2011, 18(1): 312-319[4] ZENG Rong, WANG Bo, YU Zhan-Qing et al. Opt. Eng., 2011, 50(11), 11404[5] SHEN Xiao-Kang, ZHANG Zi-Min, CAO Shu-Chun et al. Chin. Phys. C (HEP NP), 2012, 36(7): 661-665[6] Yariv A, Yeh P. Optical Waves in Crystals. New York: Wiley, 1984, 220[7] Measurement of Power Frequency Electric Field, GB/T12720-91, China, 1991 (in Chinese)[8] Gavenda J D, Foegelle M D. Proc. of the IEEE Int. Symp. Electromagnetic Compatibility. Cherry Hill, NJ, USA: 1991, 17[9] CHEN Shao-Dong, WANG Xiao-Bo, LI Bin, YANG Shao-Jie. Meteorological Monthly, 2006, 32(10): 11-19 (in Chinese)[10] ZHU Chang-Qing, LIU Shang-He, WEI Ming. High Power Laser and Particle Beams, 2005, 17(1): 99-103 (in Chinese)
