Chinese Physics C > 2013, Vol. 37 > Issue(3): 038001 DOI: 10.1088/1674-1137/37/3/038001

A high-pressure study of PbCO₃by XRD and Raman spectroscopy

Abstract
HTML
Reference
Related

PDF

Abstract：
The pressure-induced phase transitions of PbCO ₃are studied using synchrotron radiation in a diamond anvil cell at room temperature. The XRD measurement indicates that PbCO ₃with an initial phase of aragonite-type structure undergoes two phase transitions at ～ 7.8 GPa and ～ 15.7 GPa，respectively. The higher-pressure phase appearing at ～ 15.7 GPa is stable up to 51.8 GPa. The two phase transitions are further confirmed by Raman scattering up to 23.3 GPa. During the decompression process, the high-pressure phases of PbCO ₃are gradually recovered to the starting aragonite-type structure, but exhibit some hysteresis. The bulk modulus B ₀of the aragonite-type structure is obtained to be 63± (3) GPa by fitting the volume-pressure data to the Birch-Murnaghan equation of states with B ₀' fixed to 4.

References

[1]

Moses W W et al. IEEE Transactions on Nuclear Science, 1991, 38: 648-653[2] BAO Y F et al. Battery Bimonthly, 2002, 32: 230-232[3] Bakhman N N et al. Combustion and Flame, 1971，17: 383-389[4] Speer J A et al. Carbonates: Mineralgoy and Chemistry. Washington D C, 1983. 145-190[5] Chevrier G et al. Zeitschrift fur Kristallographie, 1992, 199: 67-74[6] Sytle M ANTAO et al. the Canadian Mineralogist, 2009, 47: 1245-1255[7] LIN C C et al. J. Phys. Chem. Sol., 1997b, 58: 977-987[8] LIN C C et al. Phys. Chem. Miner., 1997a, 24: 149-157[9] Catalli K, Santillian J et al. Phys. Chem. Miner., 2005, 32: 412-417[10] Robert Minch et al. Phys. Chem. Miner., 2010, 37: 45-56[11] MAO H K, XU J, Bell P M et al. J. Geophys. Res., 1986, 91: 4673-4676[12] Hammersley A P et al. High Press Res., 1996, 14: 235-248[13] Larson A C, Von Dreele R B. General Structure Analysis System, Los Alamos National Laboratory Report LAUR, 2004. 86-748[14] Aderson O L. Equation of State of Solids for Geophysics and Ceramic Science. New York: Oxford University, 1995.[15] Herman R G, Bogdan C E et al. Appl. Spectrosc., 1987, 41: 437-440[16] Coleyshaw E E, Griffith W P et al. Spectrochimica Acta, 1994, 50A: 1909-1918

Access

Get Citation

ZHANG Yu-Feng, LIU Jing, QIN Zhen-Xing, LIN Chuan-Long, XIONG Lun, LI Rui and BAI Li-Gang. A high-pressure study of PbCO ₃by XRD and Raman spectroscopy[J]. Chinese Physics C, 2013, 37(3): 038001. doi: 10.1088/1674-1137/37/3/038001

RIS(for EndNote,Reference Manager,ProCite)

BibTex

Txt

Milestone

Received: 2012-04-18
Revised: 2012-06-07

Article Metric

Article Views(3827)
PDF Downloads(399)
Cited by(0)

Policy on re-use

To reuse of subscription content published by CPC, the users need to request permission from CPC, unless the content was published under an Open Access license which automatically permits that type of reuse.

通讯作者:陈斌, bchen63@163.com

1.
沈阳化工大学材料科学与工程学院沈阳 110142

A high-pressure study of PbCO₃by XRD and Raman spectroscopy

Corresponding author:ZHANG Yu-Feng,

Corresponding author:LIU Jing,

Received Date:2012-04-18
Accepted Date:2012-06-07
Available Online:2013-03-05

Abstract:The pressure-induced phase transitions of PbCO₃are studied using synchrotron radiation in a diamond anvil cell at room temperature. The XRD measurement indicates that PbCO₃with an initial phase of aragonite-type structure undergoes two phase transitions at ～ 7.8 GPa and ～ 15.7 GPa，respectively. The higher-pressure phase appearing at ～ 15.7 GPa is stable up to 51.8 GPa. The two phase transitions are further confirmed by Raman scattering up to 23.3 GPa. During the decompression process, the high-pressure phases of PbCO₃are gradually recovered to the starting aragonite-type structure, but exhibit some hysteresis. The bulk modulusB₀of the aragonite-type structure is obtained to be 63± (3) GPa by fitting the volume-pressure data to the Birch-Murnaghan equation of states withB₀' fixed to 4.
