Alignment of the photoelectron spectroscopy beamline at NSRL

Abstract：

The photoelectron spectroscopy beamline at National Synchrotron Radiation Laboratory (NSRL) is equipped with a spherical grating monochromator with the included angle of 174°. Three gratings with line density of 200,700 and 1200 lines/mm are used to cover the energy region from 60 eV to 1000 eV. After several years' operation,the spectral resolution and flux throughput were deteriorated,and realignment was necessary to improve the performance. First,the wavelength scanning mechanism,the optical components position and the exit slit guide direction are aligned according to the design value. Second,the gratings are checked by Atomic Force Microscopy (AFM) and then the gas absorption spectrum is measured to optimize the focusing condition of the monochromator. The spectral resolving power E/ΔEis recovered to the designed value of 1000@244 eV. The flux at the end station for the 200 lines/mm grating is about 10 ¹⁰photons/sec/200 mA,which is in accordance with the design. The photon flux for the 700 lines/mm grating is about 5×10 ⁸photons/sec/200mA,which is lower than expected. This poor flux throughput may be caused by carbon contamination on the optical components. The 1200 lines/mm grating has roughness much higher than expected so the diffraction efficiency is too low to detect any signal. A new grating would be ordered. After the alignment,the beamline has significant performance improvements in both the resolving power and the flux throughput for 200 and 700 lines/mm gratings and is provided to users.
