Tuning method for nonuniform traveling-wave accelerating structures

Abstract
HTML
Reference
Related

PDF

Abstract：
The tuning method of uniform traveling-wave structures based on the non-resonant perturbation field distribution measurement has been widely used in tuning both constant-impedance and constant-gradient structures. In this paper, the method of tuning nonuniform structures is proposed on the basis of the above theory. The internal reflection coefficient of each cell is obtained from analyzing the normalized voltage distribution. A numerical simulation of tuning process according to the coupled cavity chain theory has been done and the result shows each cell is in right phase advance after tuning. The method will be used in the tuning of a disk-loaded traveling-wave structure which is being developed at the Accelerator Laboratory, Tsinghua University.
