Chinese Physics C > 2013, Vol. 37 > Issue(1): 016101 DOI: 10.1088/1674-1137/37/1/016101

Development of front-end readout electronics for silicon strip detectors

Abstract
HTML
Reference
Related

PDF

Abstract：
The front-end readout electronics has been developed for silicon strip detectors at our institute. In this system an Application Specific Integrated Circuit (ASIC) ATHED is used to realize multi-channel energy and time measurement. The slow control of ASIC chips is achieved by parallel port and the timing control signals of ASIC chips are implemented with the CPLD. The data acquisition is carried out with a PXI-DAQ card. The software has a user-friendly GUI developed with LabWindows/CVI in Windows XP operating system. The test results show that the energy resolution is about 1.14% for alpha at 5.48 MeV and the maximum channel crosstalk of system is 4.60%. The performance of the system is very reliable and suitable for nuclear physics experiments.
