Chinese Physics C > 2012, Vol. 36 > Issue(9): 895-899 DOI: 10.1088/1674-1137/36/9/018

Calculations of operating schemes for a passive harmonic cavity in HLS-Ⅱ

Abstract
HTML
Reference
Related

PDF

Abstract：
A passive higher harmonic cavity (HHC) will be used in the Hefei Light Source II Project (HLS-Ⅱ) to lengthen the bunch and consequently increase the beam lifetime dominated by Touschek scattering. The effects of constant voltage and constant detuning have been calculated and compared over the operating current from 0.4 to 0.2 A on the bunch lengthening for the passive normal conducting harmonic cavity system in HLS-Ⅱ. The results show that the bunch shape has less change and the lifetime improvement factors are not less than 2.7 over the beam currents for the constant voltage case. The constant voltage operating scheme may be applied to our machine.

References

[1]

Migliorati M, Palumbo L, Zobov M. Nucl. Instrum. Methods Phys. Res. Sect. A, 1995, 354: 215-223[2] Bosch R A, Hsue C S. Part. Accel., 1993, 42: 81[3] Weihreter E et al. IEEE Trans. Nucl. Sci., 1985, 32: 2317-2319[4] Byrd J M, Georgsson M. Phys. Rev. ST Accel. Beams, 2001, 4: 030701[5] Hofmann A, Meyers S. 11th Conf. on High Energy Accelerators, 1980. 610-612[6] Penco Giuseppe, Svandrlik Michele. Phys. Rev. ST Accel. Beams, 2006, 9: 044401[7] LIU Guang-Chao. Preliminary Investigations of Higher Harmonic Cavity's Theory (M.S.Thesis). University of Science and Technology of China. 2010 (in Chinese)
