Design and simulation of a C-band pulse compressor

Abstract
HTML
Reference
Related

PDF

Abstract：
The design and optimization procedure of a pulse compressor is presented. A C-band (5712 MHz) pulse compressor using a TE _0;1;15mode cylindrical cavity with dual side-wall coupling irises has been designed. Also the coupling coeffcient, position of the short plane and size of the bottom groove have been optimized by using HFSS.
