Chinese Physics C > 2012, Vol. 36 > Issue(11): 1120-1125 DOI: 10.1088/1674-1137/36/11/015

MIA analysis of FPGA BPMs and beam optics at APS

Abstract
HTML
Reference
Related

PDF

Abstract：
Model independent analysis, which was developed for high precision and fast beam dynamics analysis, is a promising diagnostic tool for modern accelerators. We implemented a series of methods to analyze the turn-by-turn BPM data. Green's functions corresponding to the local transfer matrix elements R ₁₂or R ₃₄are extracted from BPM data and fitted with the model lattice using least-square fitting. Here, we report experimental results obtained from analyzing the transverse motion of a beam in the storage ring at the Advanced Photon Source. BPM gains and uncoupled optics parameters are successfully determined. Quadrupole strengths are adjusted for fitting but can not be uniquely determined in general due to an insufficient number of BPMs.

References

[1]

Irwin J, WANG C X, YAN Y et al. Phys. Rev. Lett., 1999, 82(8): 1684[2] WANG Chun-Xi. Model Independent Analysis of Beam Centroid Dynamics in Accelerators. Ph.D. dissertation, Stanford University, 1999. Also available as SLAC-R-547[3] WANG C X, Borland M, Sajaev V, Kim K. BPM System Evaluation Using Model Independent Analysis. PAC2001, 2001, 1354[4] WANG Chun-Xi, John Irwin, Karl Bane, CAI Yun-Hai, Michiko Minty, Franz J. Decker, YAN Yi-Ton. SLAC-PUB-7909, 1999[5] WANG Chun-Xi. Phys. Rev. ST Accel. Beams, 2003, 6: 104001[6] WANG Chun-Xi. Measurement and Application of Betatron Modes with MIA. Particle Accelerator Conference, 2003
