Chinese Physics C > 2012, Vol. 36 > Issue(10): 1004-1008 DOI: 10.1088/1674-1137/36/10/016

RF knock-out extraction in HITFiL

Abstract
HTML
Reference
Related

PDF

Abstract：
A compact facility for cancer therapy has been designed and is presently under construction. A slow beam extraction system using the RF-Knock Out method and 3rd-order resonance is adopted in the synchrotron of this facility. Eight sextupoles are used, four of them are for correcting the chromaticity and the rest for driving the 3rd-order resonance. In order to save the aperture of vacuum chamber, a 3-magnet bump is adopted during the extraction process. The extraction phase space map and the last 3 turns' particle trajectory before extraction are given. The matching betatron functions with HEBT (high energy beam transport) are also presented.
