Chinese Physics C > 2011, Vol. 35 > Issue(8): 769-773 DOI: 10.1088/1674-1137/35/8/013

Radiation induced inter-device leakage degradation

Abstract
HTML
Reference
Related

PDF

Abstract：
The evolution of inter-device leakage current with total ionizing dose in transistors in 180 nm generation technologies is studied with an N-type poly-gate field device (PFD) that uses the shallow trench isolation as an effective gate oxide. The overall radiation response of these structures is determined by the trapped charge in the oxide. The impacts of different bias conditions during irradiation on the inter-device leakage current are studied for the first time in this work, which demonstrates that the worst condition is the same as traditional NMOS transistors. Moreover, the two-dimensional technology computer-aided design simulation is used to understand the bias dependence.

References

[1]

Brady F T, Maimon J, Hurt M. IEEE Trans. Nucl. Sci., 1999, 46: 18362 Manghisoni M, Ratti L, Re V, Speziali V, Traversi G, Candelori A. IEEE Trans. Nucl. Sci., 2003, 6: 18273 Re V, Manghisoni M, Ratti L, Speziali V, Traversi G. IEEE Trans. Nucl. Sci., 2006, 53: 15994 Faccio F, Cervelli G. IEEE Trans. Nucl. Sci., 2005, 52: 24135 Shaneyfelt M R, Dodd P E, Draper B L, Flores R S. IEEE Trans. Nucl. Sci., 1998, 45: 25836 McLain M, Barnaby H J, Holbert K E, Schrimpf R D, Shah H, Amort A, Baze M,Wert J. IEEE Trans. Nucl. Sci., 2007, 54: 22107 EN Y F, LIN C L, LUO H W, QIAN C, SHI Q, WANG X, WANG X H, WANG Y M, ZHANG E X, ZHANG Z X, ZHAO G R. Chin. Phys., 2006, 15: 7928 LI D M, WANG Z H, Huangfu L Y, GUO Q J. Chin. Phys., 2007, 16: 37609 Faccio F, Barnaby H J, CHEN X J, Fleetwood D M, Gonella L, Mclain M, Schrimpf R D. Microelectronics Reliability, 2008, 48: 100010 Witczak S C, Lacoe R C, Osborn J V, Hutson J M, Moss S C. IEEE Trans. Nucl. Sci., 2005, 52: 260211 Boesch H E, McGarrity J M. IEEE Trans. Nucl. Sci., 1976, 23: 1520
