Chinese Physics C > 2011, Vol. 35 > Issue(7): 638-641 DOI: 10.1088/1674-1137/35/7/008

A study of the active thermal control for the high energy detector on the HXMT

Abstract
HTML
Reference
Related

PDF

Abstract：
A thermal control system (TCS) based on the resistance heating method is designed for the High Energy Detector (HED) on the Hard X-ray Modulation Telescope (HXMT). The ground-based experiments of the active thermal control for the HED with the TCS are performed in the ambient temperature range from -15 to 20 ℃ by utilizing the pulse width to monitor the interior temperature of a NaI(Tl) crystal. Experimental results show that the NaI(Tl) crystal's interior temperature is from 17.4 to 21.7 ℃ when the temperature of the PMT shell is controlled within (20±3) ℃ with the TCS in the interesting temperature range, and the energy resolution of the HED is maintained at 16.2% @ 122 keV, only a little worse than that of 16.0% obtained at 20 ℃. The average power consumption of the TCS for the HED with a low-emissivity shell is about 4.3 W, which is consistent with the simulation.

References

[1]

LI T P. Nucl. Phys. B, 2007, 166: 131-1392 Birks J. The Theory and Practice of Scintillation Counting. Oxford: Pergamon Press, 1964. 453-4693 Knoll G F. Radiation Detection and Measurement. 3rd ed. New York: John Wiley Sons Inc., 1999. 234-2384 Pausch G, Stein J, Teo lov N. IEEE Trans. Nucl. Sci., 2005, 52: 1849-18555 HOU Zeng-Qi, HU Jin-Gang. Spacecraft Thermal Con- trol Technology: Princle and Application. Beijing: Science Press, 2007. 273-277 (in Chinese)6 Gilmore D G. Spacecraft Thermal Control Handbook Vol- ume 1: Fundamental Technologies. 2nd ed. California: Aerospace Press, 2002. 223-2467 LI Yan-Guo, LI Ti-Bei. Nuclear Electronics Detection Technology, 2003, 23: 391-396 (in Chinese)8 ZHANG Y et al. Nucl. Instrum. Methods A, 2010, 615: 272-276
