Simulation of beam size multiknobs correction at the Accelerator Test Facility 2 at KEK

Abstract：

The ATF2 project is the final focus system prototype for the ILC and CLIC linear collider projects, with a purpose of reaching a 37 nm vertical beam size at the interaction point (IP). During the initial commissioning, we started with larger-than-nominal β-functions at the IP in order to reduce the effects from higher-order optical aberrations and thereby simplifying the optical corrections needed. We report on the simulation studies at two different IP locations developed based on waist scan, dispersion, coupling and βfunction multiknobs correction in the large βoptics of ATF2, in the presence of two kinds of magnet inaccuracies (quadrupole gradient and roll errors) to generate all possible linear optic distortions at the IP. A vertical beam size which is very close to the nominal beam size is obtained based on the simulation study.
