Study of a compact external magnetic field radial split-cavity oscillator

Abstract
HTML
Reference
Related

PDF

Abstract：
With the experiment result analyses of a coaxial virtual cathode oscillator (CVCO), a new kind of compact radial split cavity oscillator (RSCO) is presented in this paper. On the oscillator, a low resistance tube is formed by using the diode structure of a CVCO, and a radial split-cavity structure is formed by several meshes that cause the electronic beam to transmit. Calculating all kinds of parameter, at the input parameter 350 kV, 27 kA, the numerical simulation results show that the average output microwave power is about 4.0 GW, the microwave frequency is 1.37 GHz, and the electronic efficiency is 42.3%.

References

[1]

Marer Barry M et al. IEEE Transactions on Plasma Science, 1992, 20(3): 3122 LUO Xiong, LIAO Cheng, MENG Fan-Bao et al. High Power Laser and Particle Beams, 2006, 18: 249 (in Chinese)3 LUO Xiong, LIAO Cheng, MENG Fan-Bao et al. Acta Phys. Sin., 2006, 55: 5774 (in Chinese)4 SHAO Hao, LIU Guo-Zhi. Acta Phys. Sin., 2001, 50: 2387 (in Chinese)5 Raymond W. J. Appl. Phys., 1992, 72(9): 44226 FAN Zhi-Kai, LIU Qing-Xiang. Acta Electronica Sinica, 2001, 29(4): 5387 ZHANG Ke-Qian, LI D J. Electromagnetic Theory for Microwaves and Optoelectronics. Beijing: Publishing House of Electronics Industry, 2001 (in Chinese)8 Raymond W. J. Appl. Phys., 1992, 72(9): 44229 Charles M K, Louis F L. IEEE Trans. on AP, 1994, 42(8): 118810 Courtney C C. Electronic Letters, 2002, 38(11): 496
