Chinese Physics C > 2011, Vol. 35 > Issue(3): 278-281 DOI: 10.1088/1674-1137/35/3/012

A comparison study of on-chip short pulse generation circuits based on a coplanar waveguide

Abstract
HTML
Reference
Related

PDF

Abstract：
A few traditional pulse-forming circuits are implemented in a commercial 0.13 μm digital complementary-metal-oxide-semiconductor (CMOS) technology. These circuits, based on a coplanar waveguide, are analyzed and compared through Cadence ^TMSpectre simulations. The results show that these traditional pulse-forming-line (PFL) based circuits can be implemented in standard CMOS technology for short pulse generations. Further work is needed to explore the potential of the circuit techniques and to minimize parasitic effects.

References

[1]

Mankowski J, Kristiansen M. IEEE Transactions on Plasma Science, 2000, 28: 1022 Edl Schamiloglu, Martin Gundersen. Proceedings of the IEEE, 2004, 92: 10143 Glosoe G N, Lebacqz J V. Pulse Generators. New York: McGraw-Hill, 1948. 4654 Geun-Hie Rim, Evgeny P Pavlov, Hong-Sik Lee et al. IEEE Transactions of Plasma Science, 2003, 31: 1965 Gennady A. Mesyats, Pulsed Power. US, Springer, 2005. 17
