Study on the HOMs coupler design of spoke cavity

Abstract
HTML
Reference
Related

PDF

Abstract：
The superconducting spoke cavity has been proposed to accelerate the proton in the low energy section of high power proton linac for an Accelerator Driven Sub-critical System (ADS). Considering that the High Order Modes (HOMs) in the superconducting cavity have far reaching influence on power dissipation and beam stability, the analysis of HOMs of the spoke cavity is needed. In this paper, we put emphasis on the analysis of HOMs of the spoke cavity and the HOMs coupler design.
