Chinese Physics C > 2011, Vol. 35 > Issue(11): 1042-1046 DOI: 10.1088/1674-1137/35/11/012

Simulation and experiments of rf tuning of a 201.5 MHz four-rod RFQ cavity

Abstract
HTML
Reference
Related

PDF

Abstract：
A four-rod radio frequency quadruple (RFQ) cavity has been built for the Peking University Neutron Imaging Facility (PKUNIFTY). The rf tuning of such a cavity is important to make the field distribution flat and to tune the cavity's resonant frequency to its operating value. Plate tuners are used to tune the RFQ, which have an effect on both the cavity frequency and field distribution. The rf performance of the RFQ and the effect of plate tuners are simulated. Based on the simulation, a code RFQTUNING is designed, which gives a fast way to tune the cavity. With the aid of the code the cavity frequency is tuned to 201.5 MHz and the flatness deviation of the field distribution is reduced to less than 5%.

References

[1]

GUO Zhi-Yu, LU Yuan-Rong, YAN Xue-Qing et al. Proc. of LINAC, 2006, THP042: 6732 ZHANG Chuan, GUO Zhi-Yu, Schemmp A et al. Nucl. Instrum. Methods A, 2004, 521: 3263 YAN Xue-Qing, ZHU Kun, LU Yuan-Rong et al. Nucl. Instrum. Methods A, 2010, doi: 10.1016/j.nima.2010.12.0284 WEN Wei-Wei, ZOU Yu-Bin, TANG Guo-You et al. Nucl. Instrum. Methods A, 2010, doi: 10.1016/j.nima.2010.12.1945 Fischer P, Schempp A. Proc. of LINAC, 2006, THP064: 7286 FANG Jia-Xun, Schemmp A. Proc. of EPAC, 1992, 13317 ZHU Kun, GUO Zhi-Yu, FANG Jia-Xun et al. HEP NP, 2005, 29(5): 512 (in Chinese)8 Fischer P, Nueller N, Schemmp A et al. Proc. of PAC, 2007, THPMN015: 27379 Fischer P, Schemmp A. Proc. of EPAC, 2006, TUPLS040: 158310 Schemmp A, Brendel L, Hofmann B et al. Proc of LINAC, 2004, THP10: 61711 ZHU Kun, LU Yuan-Rong, GUO Zhi-Yu et al. Test Bench of RF Cavity Cold Model, The 3nd Partical Accelerator Technology Conference, 2007.512 (in Chinese)
