Drift field improvement and test in a GEM-TPC prototype

Abstract
HTML
Reference
Related

PDF

Abstract：
With the help of Maxwell, Ansys and Garfield, a simulation of the electric field and the deviation of electron drift in the drift volume of a GEM-TPC prototype has been accomplished under the following conditions: Field Cages with one-side and double-side strips, with and without a guard ring. The advantage and necessity of a Field Cage with mirror strips and a guard ring were foreseen. According to the simulation results, TU-TPC was modified and tested; a larger effective area and better resolution were achieved.
