PIC mode simulation of solenoid collimation channel

Abstract
HTML
Reference
Related

PDF

Abstract：

A new SSC (Separated Sector Cyclotron)-Linac is being designed to serve as an injector for
the SSC at the HIRFL (Heavy Ion Research Facility Lanzhou). The beam intensity at the LEBT
(Low Energy Beam Transport) for the heavy ions after the selection is typically low and the space charge effects are inconspicuous. The space charge effects become obvious when the beam current increases to a few hundred microamperes. The emittance growth deriving from the space charge effects may be particularly troublesome for the following linac and cyclotron. An optical system containing three solenoids has been designed for the LEBT to limit the beam emittance and to avoid the unnecessary beam loss in the cyclotron, as well as for the purpose of immunizing the LEBT emittance growth due to the space charge effects. The results of the PIC (Particle-In-Cell) mode simulation illustrate that this channel could limit the beam emittance growth and increase the beam brightness.
