Chinese Physics C > 2010, Vol. 34 > Issue(7): 1005-1008 DOI: 10.1088/1674-1137/34/7/014

Thermal analysis for the high duty cycle PIMS accelerator

Abstract
HTML
Reference
Related

PDF

Abstract：

To develop the high power proton linear accelerator for the Accelerator Driven System (ADS) program, the preliminary design of the Pi mode accelerating structure (PIMS) has been carried out. It is estimated that PIMS would heat up to 80 ℃ for low duty cycle (0.1%) without water-cooling, which is not acceptable, thus water-cooling is demanded. The structure stability for the high duty cycle or even for CW operation is crucially important for the ADS application. Therefore, thermal analysis with water-cooling for a high duty accelerator in our ADS research is performed to control the frequency shift caused by a temperature rise.

References

[1]

. Mosnier A et al. Survey of High-Power Proton Linacs. Proc.of Linac2002, 2002. 821-8252. Kustom R L et al. An Overview of the Spallation NeutronSource Project. Proc. of Linac2000, 2000. 321-3253. Accelerator Group. JAERI/KEK Joint Project Team. Ac-celerator Technical Design Report for J-PARC. JAERI,KEK, 20034. Wegner R, Gerigk F. PIMS-A Simple and Robust Accel-erating Structure for High Intensity Proton Linacs. NIMA,2009, 606(3): 257-2705. Billen J H, Young L M. POISSON SUPERFISH. LA-UR-96-1834, LANL6. Wangler T P. Principles of RF Linear Accelerators. NewYork: John Wiley Sons, INC, 1998. 1227. Bourquin P et al. Development Status of the Pi-mode Accelerating Structure (PIMS) for LINAC4. Proc. of Linac2008, 2008. 939-9418. LIU Hua-Chang, OUYANG Hua-Fu. Chinese Physics C,2008, 32(4): 280-284
