Thermal analysis of the CSNS H^－ion source

WU Xiao-Bing,
OUYANG Hua-Fu^,

Abstract
HTML
Reference
Related

PDF

Abstract：

There are two cooling systems to maintain the thermal stability of the CSNS H^－ion source during its operation: Air-cooling in the source body of the discharging chamber and water-cooling in the flange on which the discharging chamber is installed. The optimal cooling parameters to ensure the operation of the H^－ion source are determined through a thermal analysis. In addition, a transient analysis is also performed to know exactly the transient temperature variation during the whole 40 ms period of the pulsed mode operation of the ion source.
