Chinese Physics C > 2010, Vol. 34 > Issue(4): 496-498 DOI: 10.1088/1674-1137/34/4/015

Tuning for the first 9-cell TESLA cavity of PKU

Abstract
HTML
Reference
Related

PDF

Abstract：
A method based on circuit model is used to tune the first home-made 9-cell TESLA type superconducting niobium cavity at Peking University. After tuning, a flat field profile with a final π-mode frequency within 3 kHz of target frequency is achieved. The field flatness is measured by a bead-pull method, and the relative electric field is calculated from the frequency shift perturbed by the bead stepping along the axis of the cavity.
