Electro-optical sampling non-synchronous delay scanning measurement ofelectron beam bunch length at BFEL

Abstract
HTML
Reference
Related

PDF

Abstract：

The Electro-optical sampling delay scanning technique can be used for electron beam bunch length measurement. A novel non-ynchronous delay scanning technique based on the electro-optical sampling measurements is presented. Based on Beijing Free Electron Laser (BFEL), the electron beam bunch length was measured with the electro-optical sampling technique for the first time in China. The result shows that the electron beam bunch length at BFEL is about 5.6±1.2 ps.
