Chinese Physics C > 2010, Vol. 34 > Issue(2): 198-203 DOI: 10.1088/1674-1137/34/2/008

Development of a prototype of the ME readout electronics onboard the HXMT satellite

Abstract
HTML
Reference
Related

PDF

Abstract：

A prototype of the ME readout electronics onboard the Hard X-ray Modulate Telescope (HXMT) satellite is developed. Application Specific Integrated Chip (ASIC) is used to construct the front end electronics due to a large number of detectors. Field Programmable Gate Array (FPGA) is connected to the ASIC as a state machine controller and data FIFO in the DAQ system. A USB board is designed to communicate between the DAQ system and the computer. The design goals and features, the operation of the system and the preliminary performance of the prototype are described. The testing results show that the design goals of the prototype system have been achieved.

References

[1]

. LI Ti-Pei. Nuclear Physics B (Proc. Suppl.), 2007, 166:131-1392. WU Y P, REN D H, YOU Z. Advances in Space Research,2004, 34: 2667-26723. LU F J, ZHANG S, WU B B, CHEN Y, CAO X L, ZHANGZ, DENG J K, ZHANG S N, LI T P. The Hard X-ray Mod-ulation Telescope (HXMT) Mission, in Astrophysics withAll-sky X-Ray Oberservations. Proceedings of the RIKEN Symposium, held 10-12 June, 2008, RIKEN and JAXA.Suzuku Umetaro Hall, RIKEN Wako, Saitama, Japan.,P.3684. Tumer T O. Test Results of a CdZnTe Pixel Detector Read Out by RENA-2 IC. Nuclear Science Symposium Confer-ence Record, 2004, IEEE5. Maeding D G. Readout Electronics for Nuclear Applica-tions (RENA) IC. Society of Photo-Optical Instrumenta-tion Engineers, 1998
